PT-1C - Connecting the PT-1C

5

4

Connecting the PT-1C

Always switch off the power to each device before connecting it to your
PT-1C. After connecting your PT-1C, switch on the power to each

device.

To connect the PT-1C as illustrated in the example in

Figure 2

:

1. Connect the HDMI source (for example, a DVD player) to the HDMI IN

connector.

2. Connect the HDMI OUT connector to an HDMI acceptor (for example, a

display).

Figure 2: Connecting the PT-1C EDID Processor
