PT-101DP - Defining the PT-101DP DisplayPort Repeater
4
Defining the PT-101DP DisplayPort Repeater
This section defines the
PT-101DP.
Figure 1: PT-101DP DisplayPort Repeater
#
Feature
Function
1
INPUT DP Connector
Connects to a DisplayPort source
2
ON LED
Lights green when the unit is powered on
3
OUTPUT DP Connector
Connects to a DisplayPort acceptor
4
EQ Button
Press (High) for equalization of longer cables,
release (Low) for shorter cables
5
5V DC Connector
Connects to the 5V DC power adapter
