PT-101DP - Technical Specifications

Technical Specifications

INPUT:

1 DisplayPort connector

OUTPUT:

1 DisplayPort connector

BANDWIDTH:

Supports up to 1.62 Gbps or 2.7Gbps per lane

(Note: Transmission range is very limited for resolutions

approaching 2560x1650)

RANGE:

35m (115ft) @UXGA/1080p using Kramer cables

COMPLIANCE WITH

STANDARDS:

Supports DisplayPort 1.1a and HDCP 1.3

INDICATOR:

ON LED

POWER CONSUMPTION:

5V DC, 1.1A

OPERATING TEMPERATURE:

0° to +40°C (32° to 104°F)

STORAGE TEMPERATURE:

-40° to +70°C (-40° to 158°F)

HUMIDITY:

10% to 90%, RHL non-condensing

DIMENSIONS:

6.22cm x 5.23cm x 3.20cm (2.5" x 2.1" x 1.3"), W, D, H

WEIGHT:

0.07kg (0.16lbs) approx.

ACCESSORIES:

Power supply

OPTIONS:

RK-4PT 19” rack adapter

Specifications are subject to change without notice at
