690T, 690R - Technical Specifications
5
Technical Specifications
690T
690R
INPUTS:
2 SDI/HD
−SDI/3G-SDI on BNC
connectors
2 LC optical connectors
OUTPUTS:
2 LC optical connectors
2 SDI/HD
−SDI/3G-SDI on BNC
connectors
BANDWIDTH:
Supports up to 3Gbps bandwidth for each input
FIBER OPTIC
EXTENSION:
Up to 10km (>6.2 miles) for 3G-SDI
INPUT CABLE
EQUALIZATION
200m for SDI, 100m for 3G-SDI
FIBER-OPTIC
CONNECTION:
Dual single mode fiber (9/125) over LC connectors
POWER SOURCE:
5V DC, 480mA
5V DC, 350mA
OPERATING
TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE
TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
6.2cm x 5.2cm x 2.4cm (2.4" x 2.0" x 0.9") W, D, H
WEIGHT:
0.14kg (0.31lbs) approx each
ACCESSORIES:
1 Power supply
OPTIONS:
RK-4PT rack adapter
Specifications are subject to change without notice a
