670T, 670RN - Connecting the 670T, 670RN 7
4 Connecting the 670T, 670RN
Always switch off the power to each device before connecting it to your
670T, 670RN. After connecting your 670T, 670RN, connect its power
and then switch on the power to each device.
Avoid direct eye exposure into the optic connectors when powered,
although this product is regulated strictly enough to operate under the
Laser Class 3R for eye safety
To connect the 670T and 670RN, as illustrated in the example in Figure 3 , do the
following:
1. Connect an HDMI source (for example a Blu-ray disc player) to the HDMI IN
connector.
2. Connect the HDMI OUT connector to an HDMI acceptor (for example, an
LCD display).
3. Remove the dust caps and connect the OPTIC CABLE connector of the
670T to the OPTIC CABLE connector of the 670RN, via optic OM3 cabling
with SC connectors (maximum range of 1700m (over 5570ft)).
4. Connect the 5V DC power adapter to the power socket on each unit and
connect the adapter to the mains electricity (not shown in Figure 3 ).
