Using the 648 FireWire 800/1394b Optical Repeater
7
5. Check if the POWER LEDs on both 648 units are lit 1 .
6. For the 648 units that did not power up, connect the 12V DC power adapters
to the power socket and connect the adapters to the mains electricity (not
shown on Figure 3).
Make sure that this time the POWER LED lights on each unit.
Video Camcorder
Host
Computer
Figure 3: Connecting the 648 FireWire 800/1394b Optical Repeater to a Peripheral Device
1 If the POWER LED on both units light, the FireWire link is set up correctly and the system is ready for use. If one or both
of the POWER LEDs do not light, continue this connecting procedure
