6 613T, 613R - Using the 3G-SDI Mini Optical Set
4 Using the 3G-SDI Mini Optical Set
This section describes how to:

Connect the detachable optical 3G-SDI Mini Optical Transmitter/ Receiver
(see Section ‎4.1 )

Avoid pitfalls when using the 613T and 613R (see Section ‎4.2 )
4.1 Connecting the 3G-SDI Mini Optical
Transmitter/Receiver Set
To connect the 613T 3G-SDI Mini Optical Transmitter with the 613R 3G-SDI Mini
Optical Receiver, as the example in Figure 1 illustrates, do the following:
1. Connect the BNC connector of the SDI Source (for example, a camera)
directly to the 613T BNC connector.
Avoid using any intermediate cable which may result in signal quality deterioration.
2. Plug the 5V power adapters to the transmitter and to the receiver, and
connect the adapters to the mains electricity.
The blue LED lights.
3. Connect the 613R BNC connector directly to the BNC connector of the display
device.
4. Remove the protective cover from the optic fiber ST connector on the 613T
and connect to the fiber optic cable.
Use glass single-mode fiber optic cable with 1310, 1550nm bandwidth on ST
connectors.
5. Remove the protective cover from the optic fiber ST connector on the 613R
and connect to the other side of the fiber optic cable.
6. Turn ON the power on the source and the display devices.
