Connecting Your SP-10D Digital Video Processor
9
6 Connecting Your SP-10D Digital Video Processor
You can use your SP-10D to convert composite video, s-Video, or component
video (YUV or RGB/S) signals to composite video, s-Video, and
1
component
video (YUV, RGsB, RGBS, RGBHV). The processing can be evaluated on a
“Before/after” split-screen.
To connect the SP-10D Digital Video Processor, do the following
2
:
1. Connect the following sources to the SP-10D:
• The composite video source (for example, a video player) to
the CV INPUT BNC connector
• The s-Video source (for example, an s-Video player) to the
Y/C INPUT 4-pin connector
2. Connect the component video INPUT BNC connectors, G/Y, B/B-Y, and
R/R-Y to either a YUV or an RGB video source, as follows:
• A video player source to G/Y, R/R-Y, and B/B-Y, or
• A camera (RGBS) source to G/Y, R/R-Y, B/B-Y and SYNC
3. Connect the following acceptors to the SP-10D:
• The SPLITTER OUTPUT BNC connector to a composite
video display
• The Y/C OUTPUT 4-pin connector to an s-Video display
• The CV OUTPUT BNC connector to a composite video
display
• The five BNC OUTPUTS connectors: G/Y, B/B-Y, R/R-Y,
Vs/Cs, and Hs/Cs to a video acceptor (for example, a plasma
display)
4. Connect the LOOP BNC connector to the next SP-10D genlocked unit (if
required) and release the Term button for looping
3
.
5. Connect a genlock source to the SYNC BNC connector.
6. Connect a PC or other controller, if required (see section 6.1 ).
7. Set the DIP-switches (see section 6.2 ).
8. Connect the power cord
4
(not illustrated in Figure 2 ).
1 All output formats are always available. However, when only one output is required, connect that output of the SP-10D, and
leave the other outputs unconnected
2 Switch OFF the power on each device before connecting it to your SP-10D. After connecting your SP-10D, switch on its
power and then switch on the power on each device
3 Pushed in terminates the input. Release when the input extends to another unit
4 We recommend that you use only the power cord that is supplied with this machine
