FC-31xl - Overview
5
To adjust the vertical position (Vs) of the image, set the DIP-switches as required,
according to the next table.
In this state:
1
2
3
Shift Down (4 steps)
OFF
OFF
OFF
Shift Down (3 steps)
ON
OFF
OFF
Shift Down (2 steps)
OFF
ON
OFF
Shift Down (1 step)
ON
ON
OFF
No shift
OFF
OFF
ON
Shift Up (1 step)
ON
OFF
ON
Shift Up (2 steps)
OFF
ON
ON
Shift Up (3 steps)
ON
ON
ON
To adjust the horizontal position (Hs) of the image, set the DIP-switches as
required, according to the next table.
In this
state:
4
5
6
7
8
In this
state:
4
5
6
7
8
Shift Left
(16 steps)
OFF
OFF
OFF
OFF
OFF
No Shift
OFF
OFF
OFF
OFF
ON
Shift Left
(15 steps)
ON
OFF
OFF
OFF
OFF
Shift Right (1
step)
ON
OFF
OFF
OFF
ON
Shift Left
(14 steps)
OFF
ON
OFF
OFF
OFF
Shift Right (2
steps)
OFF
ON
OFF
OFF
ON
Shift Left
(13 steps)
ON
ON
OFF
OFF
OFF
Shift Right (3
steps)
ON
ON
OFF
OFF
ON
Shift Left
(12 steps)
OFF
OFF
ON
OFF
OFF
Shift Right (4
steps)
OFF
OFF
ON
OFF
ON
Shift Left
(11 steps)
ON
OFF
ON
OFF
OFF
Shift Right (5
steps)
ON
OFF
ON
OFF
ON
Shift Left
(10 steps)
OFF
ON
ON
OFF
OFF
Shift Right (6
steps)
OFF
ON
ON
OFF
ON
Shift Left
(9 steps)
ON
ON
ON
OFF
OFF
Shift Right (7
steps)
ON
ON
ON
OFF
ON
Shift Left
(8 steps)
OFF
OFF
OFF
ON
OFF
Shift Right (8
steps)
OFF
OFF
OFF
ON
ON
Shift Left
(7 steps)
ON
OFF
OFF
ON
OFF
Shift Right (9
steps)
ON
OFF
OFF
ON
ON
Shift Left
(6 steps)
OFF
ON
OFF
ON
OFF
Shift Right
(10 steps)
OFF
ON
OFF
ON
ON
Shift Left
(5 steps)
ON
ON
OFF
ON
OFF
Shift Right
(11 steps)
ON
ON
OFF
ON
ON
Shift Left
(4 steps)
OFF
OFF
ON
ON
OFF
Shift Right
(12 steps)
OFF
OFF
ON
ON
ON
Shift Left
(3 steps)
ON
OFF
ON
ON
OFF
Shift Right
(13 steps)
ON
OFF
ON
ON
ON
Shift Left
(2 steps)
OFF
ON
ON
ON
OFF
Shift Right
(14 steps)
OFF
ON
ON
ON
ON
Shift Left
(1 step)
ON
ON
ON
ON
OFF
Shift Right
(15 steps)
ON
ON
ON
ON
ON
