FC-31xl - EDID Factory Default Data 9
6 EDID Factory Default Data
The FC-31xl is shipped with a fixed, factory default EDID as shown in this section.
Time: 8:56:25 AM
Date: 07 December, 2010
EDID Manager Version: 1.0.0.14
___________________________________________________________________
Block 0 (EDID Base Block), Bytes 0 - 127, 128 BYTES OF EDID CODE
0 1 2 3 4 5 6 7 8 9
000 | 00 FF FF FF FF FF FF 00 2E 4D
010 | 02 00 9C 03 00 00 27 14 01 03
020 | 78 58 32 78 EF EE 91 A3 54 4C
030 | 99 26 0F 50 54 A5 6F 00 D1 C0
040 | B3 00 95 00 90 40 A9 40 81 00
050 | 81 40 81 C0 02 3A 80 18 71 38
060 | 2D 40 58 2C 45 00 12 2C 21 00
070 | 00 1E 66 21 50 B0 51 00 1B 30
080 | 40 70 36 00 12 2C 21 00 00 1E
090 | 28 3C 80 A0 70 B0 23 40 30 20
100 | 36 00 12 2C 21 00 00 1E 48 3F
110 | 40 30 62 B0 32 40 40 C0 13 00
120 | 12 2C 21 00 00 1E 00 1A
(8-9)
ID Manufacture Name : KRM
(10-11) ID Product Code : 0002
(12-15) ID Serial Number :
(16)
Week of Manufacture : 39
(17) Year of Manufacture : 2010
(18)
EDID Version Number : 1
(19) EDID Revision Number: 3
(20)
Video Input Definition: Analog
0.700, 0.000 (0.700 V p-p)
Separate Syncs
(21)
Maximum Horizontal Image Size: 88 cm
(22) Maximum Vertical Image Size: 50 cm
(23) Display Gamma : 2.20
(24) Power Management and Supported Feature(s):
Standby, Suspend, Active Off/Very Low Power, RGB Color, sRGB, Preferred Timing
Mode, Default GTF Supported
(25-34)
Color Characteristics
Red Chromaticity: Rx = 0.636 Ry = 0.330
Green Chromaticity: Gx = 0.300 Gy = 0.596
Blue Chromaticity: Bx = 0.150 By = 0.056
Default White Point: Wx = 0.312 Wy = 0.329
(35)
Established Timings I
720 x 400 @ 70Hz (IBM, VGA)
640 x 480 @ 60Hz (IBM, VGA)
640 x 480 @ 75Hz (VESA)
800 x 600 @ 60Hz (VESA)
(36)
Established Timings II
800 x 600 @ 75Hz (VESA)
832 x 624 @ 75Hz (Apple, Mac II)
1024 x 768 @ 60Hz (VESA)
1024 x 768 @ 70Hz(VESA)
1024 x 768 @ 75Hz (VESA)
1280 x 1024 @ 75Hz (VESA)
(37)
Manufacturer's Timings (Not Used)
(38-53)
Standard Timings
1920x1080 @ 60 Hz (16:9 Aspect Ratio)
1680x1050 @ 60 Hz (16:10 Aspect Ratio)
1440x900 @ 60 Hz (16:10 Aspect Ratio)
1400x1050 @ 60 Hz (4:3 Aspect Ratio)
1600x1200 @ 60 Hz (4:3 Aspect Ratio)
