ESD Ceiling Speaker - Installing the ESD Ceiling Speaker 11
3. If required, daisy-chain the next speaker (see Section 4.3
Note: Do not over-tighten the screws. It may cause damage to both the speakers
and the surface.
).
4.6 Installing the Half-Tile Size Speaker
When installing the half-tile size model:
1. Remove the ceiling tile.
2. Cut the ceiling tile in half (to 30x60cm).
3. Place the ceiling mounting bracket (supplied with the half-tile unit only)
between the ceiling rails, as illustrated in Figure 9 .
Figure 9: Placing the Ceiling Mounting Bracket
4. Drop the half-tile size speaker in the appropriate opening, so it is supported
by the ceiling rails and the ceiling mounting bracket (see Figure 10 ).
No screws are needed.
