SL-10 - Connecting the SL-10 7
4 Connecting the SL-10
Always switch off the power to each device before connecting it to your
SL-10. After connecting your SL-10, connect its power and then switch
on the power to each device.
To connect the SL-10 as illustrated in the example in Figure 2 :
1. Connect the RELAY terminal block connectors as follows:

Connect RELAY 1 and 2 to the projector lift
 Connect RELAY 3 and 4 to the screen
 Connect RELAY 5 to the lighting system
2. Connect the IR outputs as follows:
 Connect an IR emitter to IR OUTPUT 1 and attach the emitter to the
DVD player
3. Connect the GPI/O ports as follows:
 Connect GPI/O 1 to motion detector 1

Connect GPI/O 2 to motion detector 2
4. Connect the RS-232 ports as follows:
 Connect RS-232 port 1 to the DVD player
 Connect RS-232 port 2 to the projector
5. Connect the IR input as follows:
 Connect IR INPUT 1 to an IR sensor (or alternatively connect IR
INPUT 1 to an external IR receiver
P/N: C- A35M/IRR two extension cables are also available: a 15 meter cable and
a 20 meter cable.
6. Connect the RS-485 to several Kramer matrices, for example.
Not shown in Figure 2 .
7. Connect the Ethernet port to a network.
