Technical Specifications
15
15
9 Technical Specifications
The RC-74DL technical specifications
1
are shown in Table 4 .
Table 4: RC-74DL Master Room Controller Technical Specifications
INPUTS: 3 RS-232, 1 RS-485, 2 GPI/O and 2 K-NET on terminal block
connectors; Ethernet on an RJ-45 connector; 1 infrared sensor, 1 USB
for programming
OUTPUTS: 2 IR, 4 relays (36V AC or DC, 2A, 60VAC maximum on non-inductive
load) and 2 GPI/O on terminal block connectors
DEFAULT IP
SETTINGS:
IP number

192.168.1.39; Mask – 255.255.0.0; Gateway – 0.0.0.0
POWER
CONSUMPTION:
12V DC, 570mA
DIMENSIONS: 16.2cm x 2.6cm x 11.4 (6.4" x 1.0” x 4.5") W, D, H
WEIGHT: 0.6kg (1.4lbs) approx.
ACCESSORIES: Power supply, Kramer K-Config Windows®-based configuration software
OPTIONS: IR emitter cables, KPOD-301, OWB-3G
1 Specifications are subject to change without notice
