VP-774 - The VP-774 RS-232 Communication Protocol
77
77
Identification commands
Command
Syntax
Response
HH:MM:SS
Read device protocol
version
PROT-VER?
PROT-VER 3000:MAJOR
.MINOR
Set machine name
NAME MACHINE_NAME
NAME MACHINE_NAME
RESULT
Read machine name
NAME?
NAME MACHINE_NAME
Reset machine name
to factory default*
NAME-RST
NAME-RST RESULT
Network settings commands
Network settings commands require admin authorization
Command
Syntax
Response
Set IP Address NET-IP IP_ADDRESS
NTIP
NET-IP IP_ADDRESS RESULT
Read IP
Address
NET-IP?
NTIP?
NET-IP IP_ADDRESS
Read MAC
Address
NET-MAC?
NTMC?
NET-MAC MAC_ADDRESS
Set subnet
mask
NET-MASK SUBNET_MASK
NTMSK
NET-MASK SUBNET_MASK
RESULT
Read subnet
mask
NET-MASK?
NTMSK?
NET-MASK SUBNET_MASK
Set gateway
address
NET-GATE GATEWAY_ADDRESS
NTGT
NET-GATE
GATEWAY_ADDRESS RESULT
Read subnet
mask
NET-GATE?
NTGT?
NET-GATE
GATEWAY_ADDRESS
Set DHCP
mode
NET-DHCP DHCP_MODE
NTDH
NET-DHCP DHCP_MODE
RESULT
Read subnet
mask
NET-DHCP?
NTDH?
NET-DHCP DHCP_MODE
DHCP_MODE =
0 (factory default)
– Don't use DHCP (Use IP set by factory or IP set command).
1
– Try to use DHCP, if unavailable use IP as above.
2
– Try to use DHCP, if unavailable use AUTO-IP as described here:
Change
protocol
Ethernet port
ETH-PORT PROTOCOL , PORT
ETHP
ETH-PORT PROTOCOL ,PORT
RESULT
Read protocol
ETH-PORT? PROTOCOL
ETH-PORT PROTOCOL , PORT
