Kramer Electronics VP-774 - Manual (Page 80)

VP-774 - The VP-774 RS-232 Communication Protocol 75
75
Operation commands
Command Syntax Response
Power state POWER POWER-MODE POWER POWER-MODE
RESULT
Get power state POWER? POWER POWER-MODE
Parameters Description:
POWER-MODE = power state:
"0" or "off" to enter standby mode.
"1" or "on" to power up.
Restart device RESET RESET OK
Peripheral firmware
update execute* UPGRADE UPGRADE OK
Usually the firmware will upload to the device via a command such as LDFW
A device reset may be needed to complete the process
Video core Firmware
update execute* UPGRADES UPGRADES OK
Reset configuration
to factory default FACTORY FACTORY RESULT
SET dedicated EAS
port settings EAS-CFG PORTTYPE,
PORTNUM
EAS-CFG PORTTYPE,
PORTNUM RESULT
GET dedicated EAS
port settings EAS-CFG? EAS-CFG PORTTYPE,
PORTNUM
Parameters Description:
PORTTYPE either “TCP” or “UDP”
PORTNUM Ethernet port
EAS Activation Mode
notification
messages N/A EAS-EXE ACTIVATION-MODE OK
Parameters Description:
ACTIVATION-MODE = EAS notification:
“1” to notify full screen + siren activation mode (Severity = Extreme)
“2” to notify full screen activation mode (Severity = Severe)
“3” to notify crawler activation mode (Severity = Moderate \ Minor \ Unknown)
“0” to notify that the alert went off either by timeout or by keystroke
SET dedicated port
tunneling settings
PTNL-CFG PORTTYPE,
PORTNUM
PTNL-CFG CFG PORTTYPE,
PORTNUM RESULT
GET dedicated port
tunneling settings PTNL-CFG? PTNL-CFG PORTTYPE,
PORTNUM
Parameters Description:
PORTTYPE either “TCP” or “UDP”
PORTNUM Ethernet port
SET UART port tunneling
settings UART BAUD,
DATA_BITS, PARITY,
STOPBITS
UART BAUD, DATA_BITS,
PARITY, STOPBITS RESULT
GET UART port tunneling
settings UART? UART BAUD, DATA_BITS,
PARITY, STOPBITS
Parameters Description:
BAUD = 1200, 2400, 4800, 9600, 19200, 38400 57600,
