Connecting the TP-219HD and TP-220HD
9
3. On
the
TP-220HD, connect
the:
OUTPUT 1 15-pin HD connector to an XGA
acceptor (for
example, Display 1)
OUTPUT 2 15-pin HD connector to an XGA
acceptor (for
example, Display 2)
4. If necessary, set the HS and VS switches on the TP-220HD underside
.
5. Connect the LINE OUT RJ-45 connector on the TP-219HD to the LINE IN
RJ-45 connector on the TP-220HD, via CAT 5 cabling, see section
6. Connect the 12V DC power adapter to the power socket and connect the
adapter to the mains electricity on both
the TP-219HD and the TP-220HD
).
The selected signal from the XGA/HD source is transmitted via CAT 5
cable, decoded and converted at the OUTPUT 1 and OUTPUT 2 15-pin
HD connectors to the XGA acceptors simultaneously.
1 You do not have to connect both outputs
2 Alternatively, you can connect an HD acceptor, see section
5.1
3 By default, both switches are set to normal (see
Figure 4
and
Table 4
)
4 If you cannot connect the power to both the TP-219HD and TP-220HD, you can just connect the power to one of them
