VP-200K, VP-300K, VP-400K - Technical Specifications
6
Technical Specifications
INPUT:
1 UXGA on an 15-pin HD connector
OUTPUTS:
2/3/4 UXGA on 15-pin HD connectors
MAX. OUTPUT LEVEL:
2.2Vpp
BANDWIDTH (-3dB):
400MHz
DIFF. GAIN:
0.03%
DIFF. PHASE:
0.03Deg
K-FACTOR:
<0.05%
S/N RATIO:
72dB @5MHz
CONTROLS:
Internal ID BIT switch; internal analog/TTL switches for
setting the sync
COUPLING:
DC
POWER CONSUMPTION:
5V DC, 130mA
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
12.1cm x 7.18cm x 2.42cm (4.76" x 2.83" x 0.95", W, D, H)
WEIGHT:
0.3kg (0.67lbs) approx.
ACCESSORIES:
Power supply, one 3ft VGA male/male cable C-GM/GM-3,
mounting bracket
OPTIONS:
RK-3T 19" rack adapter
Specifications are subject to change without notice
