6 VM-50AN - Using Your VM-50AN 1:5 Audio Distributor
4 Using Your VM-50AN 1:5 Audio Distributor
Always switch off the power to each device before connecting it to your
VM-50AN. After connecting your VM-50AN, connect its power and
then switch on the power to each device.
This section describes how to connect the VM-50AN as:

A balanced stereo 1:5 audio distributor, see Section ‎4.1

An unbalanced stereo 1:5 audio distributor, see Section ‎4.2

A 1:10 audio distributor, see Section
‎4.3
4.1 Connecting the VM-50AN as a Balanced Stereo 1:5
Audio Distributor
To connect and operate the VM-50AN as a balanced stereo 1:5 audio distributor,
as the example in Figure 2 illustrates, do the following:
1. Connect a balanced stereo audio source (for example, a balanced stereo
player) to the INPUT terminal block connector.
2. Connect up to five balanced stereo audio acceptors (for example, balanced
stereo recorders) to the OUT terminal block connectors.
You do not have to connect all the outputs.
3. Connect the 12V DC power adapter to the power socket, connect the
adapter to the mains electricity, and then turn on the power switch.
4. Release the BAL/UNBAL INPUT MODE button to select balanced stereo
audio operation.
5. Adjust the right and/or left output signal level, if required.
Insert a screwdriver into the hole and carefully rotate it, to trim the level.
i
