VM-50AN - Technical Specifications
5
Technical Specifications
INPUTS:
1 balanced stereo audio, +4dBm 50k
on detachable
terminal block connector
1 unbalanced stereo audio, 1Vpp/50k
on mini 3.5mm
socket
OUTPUTS:
5 balanced stereo audio, +4dBm 50
on detachable
terminal block connectors
5 unbalanced stereo audio, +22dBm 470
on mini
3.5mm sockets
MAX. OUTPUT LEVEL:
>24dBm
BANDWIDTH:
>40kHz; fully loaded
S/N RATIO:
84dB, unweighted
CONTROLS:
Level (for right and left): 0.4dB to 9.5dB
COUPLING:
Input: AC; Output: DC
AUDIO THD + NOISE:
0.002% @1kHz, balanced output
AUDIO 2nd HARMONIC:
0.022% @1kHz, balanced output
POWER CONSUMPTION:
12V DC, 200mA
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
16.5cm x 12cm x 4.5cm (6.5” x 4.7” x 1.7”, W, D, H)
WEIGHT:
0.6kg (1.3lbs) approx.
ACCESSORIES:
Power supply
OPTIONS:
RK-1 19" rack adapter
Specifications are subject to change without notice
