VM-50AN - Overview 5
# Feature Function
1 POWER Switch Illuminated switch supplying power to the unit
2 INPUT MODE BAL/UNBAL Button When released, selects the balanced stereo audio
input when pushed in, selects the unbalanced
stereo audio
3 RIGHT LEVEL Trimmer Adjusts the right output signal level (use a small
screwdriver)
4 LEFT LEVEL Trimmer Adjusts the left output signal level (use a small
screwdriver)
5 INPUT 3.5mm Mini Plug Connector Connects to the unbalanced audio source
6 INPUT Terminal Block Connector Connects to the balanced audio source
7 OUT 3.5mm Mini Plug Connector Connects to the unbalanced audio acceptor (from 1
to 5)
8 OUT Terminal Block Connector Connects to the balanced audio acceptor (from 1 to
5)
