Technical Specifications
6
6 Technical Specifications
Table 2 includes the technical specifications:
Table 2: Technical Specifications
1
of the VM-312 Multi-Format Distributor
CV
COMP (YUV)
Y/C
AUDIO
INPUTS:
1 composite video
on an RCA
connector
1Vpp/75
1 component
video (Y, B-Y, and
R-Y) on RCA
connectors
1Vpp/0.7Vpp/75
1 s-Video on a 4p
connector
1Vpp/0.3Vpp/75
1 stereo
unbalanced on a
3.5mm mini jack
connector
4dBm/50k
OUTPUTS:
2 composite video
on RCA
connectors
1Vpp/75
2 component
video (Y, B-Y, and
R-Y) on RCA
connectors
1Vpp/0.7Vpp/75
2 s-Video on 4p
connectors
1Vpp/0.3Vpp/75
2 stereo
unbalanced on
3.5mm mini jack
connectors
4dBm/150
MAX. OUTPUT LEVEL: 1.8Vpp
21Vpp
BANDWIDTH (-3dB):
490MHz
450MHz
420MHz
>100kHZ
DIFF. GAIN:
0.05%
DIFF. PHASE:
0.03 Deg.
K-FACTOR:
<0.05%
S/N RATIO:
75dB
82dB
CROSSTALK (all
hostile):
–52dB @ 5MHz, YUV into CV
-45dB video into
audio @ 15kHz
COUPLING:
DC
Input: AC; output:
DC
AUDIO THD + NOISE:
0.047% @ 1kHz
AUDIO 2nd HARMONIC:
0.001% @ 1kHz
POWER SOURCE:
12V DC, 130mA DC
DIMENSIONS:
21.5cm x 16.25cm x 4.36cm (8.45” x 6.39” x 1.72”), W, D, H.
WEIGHT:
1.2 kg. (2.65 lbs.) approx.
ACCESSORIES:
Power cord
1 Specifications are subject to change without notice
