Connecting the VM-312 Multi-Format Distributor
4
5 Connecting the VM-312 Multi-Format Distributor
To connect the VM-312 as illustrated in the example in Figure 2, do the
following 1 :
1. Connect the component video source and acceptors as follows:
Connect a component video source (for example, a betacam video
player) to the Y, PB/CB, and PR/CR COMP IN RCA connectors
Connect the component video Y1, PB CB 1 and PR CR 1 COMP
OUT RCA connectors to a component video acceptor (for example, a
plasma display)
Connect the component video COMP OUT RCA connectors Y2, PB
CB 2 and PR CR 2, to a component video acceptor (for example, a
betacam video recorder)
2. Connect the composite video sources and acceptors, as follows:
Connect a composite video source (for example, a composite video
player ) to the CV IN RCA connector
Connect the CV OUT 1 RCA connector to a composite video
acceptor (for example, a composite video recorder)
Connect the CV OUT 2 RCA connector to a composite video
acceptor (for example, a composite video display)
3. Connect the s-Video sources and acceptors, as follows:
Connect an s-Video source (for example, an s-Video player ) to the
Y/C IN 4p connector
Connect the Y/C OUT 1 4p connector to an s-Video acceptor (for
example, an s-Video display)
Connect the Y/C OUT 2 4p connector to an s-Video acceptor (for
example, a projector)
4. Connect the AUDIO source and acceptors (not shown in Figure 2), as follows:
Connect an unbalanced stereo audio source to the IN 3.5mm mini jack
connector
Connect the 3.5mm mini jack OUT 1 connector to an unbalanced
stereo audio acceptor
Connect the 3.5mm mini jack OUT 2 connector to an unbalanced
stereo audio acceptor
5. Connect the 12V DC power adapter (not shown in Figure 2) to the power
socket and connect the adapter to the mains electricity.
1 You do not need to connect all the outputs
