Your VM-312 Multi-Format Video/Audio Distributor
3
Table 1: VM-312 Multi-Format Video/Audio Distributor Features
# Feature Function
1 POWER Switch Illuminated switch for turning the unit ON or OFF
2 Y1 RCA Connector
3 PB CB 1 RCA Connector
4 PR CR 1 RCA Connector
Connect to the component video acceptor1
5 Y2 RCA Connector
6 PB CB 2 RCA Connector
7
C
O
M
P
O
U
T
PR CR 2 RCA Connector
Connect to the component video acceptor 2
8 Y RCA Connector
9 PB/CB RCA Connector
10
C
O
M
P
IN
PR/CR RCA Connector
Connect to the component video source
11 IN RCA Connector Connect to the composite video source
12 OUT 1 RCA Connector
13
C
V
OUT 2 RCA Connector
Connect to the composite video acceptors (1 and 2)
14 IN 4p Connector Connect to the s-Video source
15 OUT 1 4p Connector
16
Y
/C
OUT 2 4p Connector
Connect to the s-Video acceptors (1 and 2)
17 IN 3.5 Mini Jack Connector Connect to the unbalanced stereo audio source
18 OUT 1
19
A
U
D
IO
OUT 2
3.5mm Mini Jack
Connector
Connect to the unbalanced stereo audio acceptors
(1 and 2)
20 12V DC +12 DC connector for powering the unit
