6 VM-2HDCPxl - Connecting the VM-2HDCPxl
4 Connecting the VM-2HDCPxl
Always switch off the power to each device before connecting it to your
VM-2HDCPxl. After connecting your VM-2HDCPxl, connect its power
and then switch on the power to each device.
To connect the VM-2HDCPxl as illustrated in the example in Figure 2 :
1. Connect a computer graphics source to the INPUT connector.
2. Connect the OUTPUT connectors to one or both DVI acceptors, as follows:
You do not have to connect both outputs.

OUTPUT 1 connector to DVI acceptor 1 (for example, a display)

OUTPUT 2 connector to DVI acceptor 2 (for example, a projector)
3. Connect the 5V DC power adapter (wall transformer) to the 5V DC socket
and connect the transformer to the mains electricity.
4. Acquire the EDID (see section ‎4.1 ).
