VM-2HDCPxl - Technical Specifications

Technical Specifications

INPUT:

1 DVI, 1.2Vpp on a DVI Molex 24-pin female connector;
DDC signal 5Vpp (TTL)

OUTPUTS:

2 DVI, 1.2Vpp on DVI Molex 24-pin female connectors;
DDC signal 5Vpp (TTL)

COMPLIANCE WITH
STANDARDS:

Supports DVI 1.1 and HDCP

MAX RESOLUTION:

Up to WUXGA (1920x1200), 1080p

BANDWIDTH:

6.75Gbps (2.25Gbps per graphic channel)

CONTROLS:

EDID button for selecting and storing EDID information

POWER CONSUMPTION:

5V DC, 1.1A

OPERATING TEMPERATURE:

0° to +40°C (32° to 104°F)

STORAGE TEMPERATURE:

-40° to +70°C (-40° to 158°F)

HUMIDITY:

10% to 90%, RHL non-condensing

DIMENSIONS:

12cm x 7.2cm x 2.4cm (4.7" x 2.8" 1.0") W, D, H

WEIGHT:

0.3kg (0.67lbs) approx.

ACCESSORIES:

Power supply, mounting bracket

OPTIONS:

RK-3T 19" rack adapter

Specifications are subject to change without notice at
