6 VM-10HDxl - Overview
Figure 2: VM-10HDxl 3G 1:10 HD/SD – SDI Distribution Amplifier Rear Panel
# Feature Function
4 VIDEO IN BNC connector Connects to the SDI source
5 ACTIVE LOOP BNC connector Connects to an additional unit
6 VIDEO OUTPUTS BNC connectors Connects to the SDI acceptors (from 1 to 10)
7 Power Connector with Fuse AC connector enabling power supply to the unit
6
