4 VM-10HDxl - Overview
3 Overview
The VM-10HDxl 3G 1:10 HD/SD - SDI Distribution Amplifier is a high performance
1:10 distributor for all SDI video signals.
In particular, the VM-10HDxl features:

One input and 10 identical outputs on BNC connectors

A maximum data rate of up to 3Gbps – enabling it to be used for standard
definition, high definition and 3G high definition serial digital video signals
(SD/HD/3G HD-SDI)
 Up to 300m cable equalization (300m for SD signals, 200m for 1.5Gbps HD
signals, and 100m for 3Gbps HD signals)

SMPTE 259M, 292M and 424M compliance and supports data rates of
270Mbps, 1483.5Mbps, 1485Mbps and 2970Mbps

Automatic, multi-rate, equalization and reclocking for losses typical with long
runs of 75

co-axial cable

HD and SD output indication LEDs

An active loop BNC connector for cascading additional units
3.1 Your VM-10HDxl 3G 1:10 HD/SD - SDI Distribution
Amplifier
This section defines the VM-10HDxl 3G 1:10 HD/SD - SDI Distribution Amplifier:
