5 connecting the vm-10hdxl, Connecting the vm-10hdxl, Figure 3: connecting the vm-10hdxl 3g 1:10 hd/sd – Kramer Electronics VM-10HDxl User Manual
Page 11: Sdi distribution amplifier, 5connecting the vm-10hdxl

8
VM-10HDxl - Connecting the VM-10HDxl
5
Connecting the VM-10HDxl
Always switch off the power to each device before connecting it to your
VM-10HDxl. After connecting your VM-10HDxl, connect its power and
then switch on the power to each device.
To connect the VM-10HDxl as illustrated in the example in
1. Connect an HD-SDI/SD-SDI video source (for example, an SDI camera) to
the VIDEO IN BNC connector.
2. Connect up to 10 VIDEO OUTPUT BNC connectors to the appropriate
HD-SDI/SD-SDI video acceptors (for example, displays).
You do not have to connect all the outputs.
3. Connect the power cord (not illustrated in
Figure 3: Connecting the VM-10HDxl 3G 1:10 HD/SD
– SDI Distribution Amplifier
i
