2.
SPECIFICATIONS
VM-80V
VM-10AN
Function
1:8 Video Distribution Amplifier
1:10 AV Distribution Amplifier
Inputs Type
2 Composite/single component
video 1Vpp/75ohm on BNCs with
termination switches
1 video looping, 1Vpp/75ohm on a
BNC with a termination switch.
1 stereo audio 1Vpp / 50 K ohm on
RCAs
Outputs
2x4 Composite/single component
video 1Vpp/75ohm on BNCs
10 video, 1Vpp/75ohm on BNCs
10 stereo audio 1Vpp / 100 ohm on
RCAs
Input Coupling
DC or AC (internal jumper
selection)
DC/AC internally selectable
S/N Ratio
74 dB
> 89dB @ 1V (audio), >74dB (video)
Audio Bandwidth
NA
20 kHz –1dB
Video Bandwidth
>330 MHz (-3dB)
>77 MHz (-3dB)
Max video Output
2 Vpp
2.5 Vpp
Differential Gain
0.12%
0.33%
Differential Phase
0.5Deg.
0.26Deg.
Audio THD+N
NA
<0.025%
K-Factor
<0.1%
<0.05%
Dimensions (W, D, H)
22 cm x 18cm x 4.5cm
8. 7" x 7" x 1.8"
24.5 cm x 16 cm x 5cm
9.6" x 6.3" x 2"
Weight
1.3 Kg (2.9lbs) Approx.
1.8 Kg (4 lbs.) Approx.
Power Source
100 - 240VAC, 50 / 60 Hz, 10VA.
230VAC, 50Hz, (115V USA),
10.5VA.
