Toolless mounting – American Power Conversion AP7862J User Manual
Page 8
How to Install the Basic and Metered PDU
4
Basic and Metered Rack Power Distribution Unit
Toolless mounting
1. Slide the mounting pegs into the holes located in the channel in the
rear panel of the enclosure.
2. Snap the
PDU
into place by pushing it downward until it locks into
position.
Note
You can mount two
PDU
s on one side of the enclosure by
using the toolless mounting method.
