Installation
Installation of the device requires the use of a separate adapter plate. Obtain the
adapter plate for the respective gun from specialist shops. Install the device using
the hexagon socket-head screws provided and the Allen key that is also included
in the equipment. The underside of the housing contains flat bores for the
accommodation of alignment pins providing defined positioning of the device.
Please put the protective cover on your DOCTERsight when cleaning your
gun. This prevents gun oil aerosols from setting on the light-emitting diode
or on the optical surfaces and makes sure that the shape of the dot does
not change.
Operating procedure
Elevation and windage adjustment
The sighting device contains separate controls for elevation (vertical) and
windage (lateral) adjustment. These are arranged on the top and the right side
of the sight.
To adjust the sight, turn the slotted screws using the provided adjusting wrench
with attached scale and the screwdriver 0.4 x 2.0.
The adjusting controls can be operated independently of each other. The availa-
ble adjustment range allows both compensation of inaccuracies in mounting the
sight and ballistic correction. The windage adjustment mechanism has limit stops
at both ends.
Please note that in elevation adjustment the downward stop is available in
mounted condition only.
Please note that the adjustment mechanism will be locked if you screw
down the other adjusting screw each up to the stop.
Adjusting elevation and windage
(Refer back view-illustration to title)
Before every adjustment of elevation or windage, make sure to loosen the lock
of the adjustment mechanism to avoid damage to it. For this, turn the spring-
loaded thrust and clamp screws on the rear side of the sight a quarter of a turn
counter-clockwise away from the limit stop using a screwdriver 0.4x2.0. The
adjusting controls must be smoothly movable.
