10 Scope of delivery · Specifications · Warning · Care and maintenance
ENGLISH
Scope of delivery
• 2 countersunk screws M3x8 with hexagon socket head
for installing the sight on the mounting plate
• 1 Allen key for tightening the fastening screws
• 1 screwdriver 0.4 x 2.0
• 1 adjusting wrench with adjusting scale specific for the device
• 1 protective cap
• 1 Lithium battery 3 V, CR 2032
• operating instructions
Specifications
• Magnification: 1.07 x
• Sight window: 21 mm x 15 mm
• Elevation adjustment range:
4 degrees or 720 cm @ 100 m or 260 in @ 100 yards
• Windage adjustment range: 3 degrees or 540 cm @ 100 m or 195 in @ 100 yards
• Set value for one scale division:
1 minute of arc or 1 in @ 100 yards with 60 scale divisions per turn
• Subtension of the aiming dot depending on the model:
3.5 m.o.a. / 10 cm @ 100 m / 3.5 in @ 100 yards or
7.0 m.o.a. / 20 cm @ 100 m / 7.0 in @ 100 yards
• Parallax-free sighting distance: approx. 40 yards
• Recoil resistance: at least 1000 g
• Operating temperature range: - 25°C to + 55°C / - 10°F to + 130°F
• Storage temperature range: - 40°C to + 70°C / - 40°F to + 160°F
• Power supply: 3 V with 1 x CR 2032 (Lithium)
• Dimensions (L x W x H): 46 mm x 25.4 mm x 23.7 mm
• Weight (in operating condition w/o mounting aids): 0.9 oz. / 25 grams
Warning
Remove, where present, the magazine and all ammunition from your firearm. Open
the breech and ensure there is no round in the chamber. Point the firearm in a safe
direction and decock it. Engage, where possible, the safety. Make sure to dischar-
ge the gun and put its safety catch on prior to mounting the sight. Avoid looking
directly into the sun, light arcs or other high-intensity light sources to prevent eye
damage. The equipment includes small components. Keep away from children!
Care and maintenance
Use lens-cleaning tissues for cleaning the optical surfaces. Never touch the lumi-
nous dot. Remove any dirt from it by blowing it off or using a very fine brush.
