12. Re-screw the upper hinge.
13. Fit the upper door on the upper door
pivot.
14. Re-insert the upper door on the middle
hinge pivot (c3 )slightly tilting both
doors.
15. Re-screw the middle hinge. Do not for-
get the plastic spacer.
Do a final check to make sure that:
• All screws are tightened.
• The magnetic seal adheres to the cabinet.
• The door opens and closes correctly.
If the ambient temperature is cold (i.e. in
Winter), the gasket may not fit perfectly to the cabinet. In that case, wait for the natural
fitting of the gasket.
In case you do not want to carry out the above mentioned operations, contact the nearest
After Sales Service Force. The After Sales Service specialist will carry out the reversibility of
the doors at your cost.
NOISES
There are some sounds during normal running (compressor, refrigerant circulation).
BRRR!
HISSS!
CLICK!
BLUBB!
CRACK!
SSSRRR!
OK
CLICK!
CLICK!
1
2
1
2
C1 C2
C3 C4
