MAXIBOX drawer
The drawer is suitable for storing fruit and vege-
tables.
There is a separator inside the drawer that can be
placed in different positions to allow for the sub-
division best suited to personal needs.
There is a grille (if foreseen) on the bottom of the
drawer to separate the fruit and vegetables from
any humidity that may form on the bottom sur-
face.
All parts inside the drawer can be removed for
cleaning purposes
Removal of freezing baskets from the freezer
The freezing baskets have a limit stop to prevent
their accidental removal or falling out. At the
time of its removal from the freezer, pull the bas-
ket towards yourself and, upon reaching the end
point, remove the basket by tilting its front up-
wards.
At the time of putting it back, slightly lift the
front of the basket to insert it into the freezer.
Once you are over the end points, push the bas-
kets back in their position.
HELPFUL HINTS AND TIPS
Normal Operating Sounds
• You may hear a faint gurgling and a bubbling sound when the refrigerant is pumped
through the coils or tubing. This is correct.
• When the compressor is on, the refrigerant is being pumped around and you will hear a
whirring sound and a pulsating noise from the compressor. This is correct.
• The thermic dilatation might cause a sudden cracking noise. It is natural, not dangerous
physical phenomenon. This is correct.
Hints for energy saving
To obtain the best performance:
• do not open the door frequently or leave it open longer than absolutely necessary
• do not remove the cold accumulators from the freezer basket.
Hints for fresh food refrigeration
To obtain the best performance:
• do not store warm food or evaporating liquids in the refrigerator
• do cover or wrap the food, particularly if it has a strong flavour
2
1
Helpful hints and tips 13
