Operating and Assembly Instructions:
The cap and paddle assemblies are shipped partially assembled.
Glass Rod Installation (refer to Figure 1):
Remove the magnet from the magnet holder by pushing the magnet through the
holder until free. Next, remove the impeller blade by pulling it free of the magnet
holder. Insert the glass rod (suspension shaft) into the hole in the bottom of the
magnet holder. Insert the silicone plug and then replace the impeller blade and re-
install the magnet.
Figure 1
WARNING: Be careful handling the glass shaft as accidental
breakage can cause injury
