3
4. Maintenance
No routine or extraordinary maintenance is necessary apart from periodically cleaning the unit as described in this manual.
In compliance with the product guarantee law, repairs to our units must be carried out in our factory, unless previously
agreed otherwise with local distributors.
The instrument must be transported in its original packaging and any indications present on the original packaging must be
followed (e.g. palletized).
4.1 Cleaning
Disconnect the unit from the power supply and use a cloth dampened with an non-inflammable non-aggressive detergent.
5. Technical data
Dimensions WxHxD 165x115x280 mm
Weight 2.5 kg
Overall power 630 W
Power of the heating plate 600 W
Diameter of the heating plate 135 mm
Programmable temperature range 50 – 370 °C
Type of temperature control Analog
Overtemperature protection Yes
Stirring power 30 W
Stirring capacity 20 liters of H
2
O
Programmable speed range 50 – 1200 rpm
Type of motor control Electronic
Temperature range +5…+40 °C
Storage temperature range - 10…+60 °C
Max humidity 80%
Level of electrical protection CEI EN60529 IP 42
Pollution degree CEI EN61010-1 2
6. Wiring diagram
1. Fuse
2. ON-OFF switch
3. Electric motor
4. Electronic board
5. Controls electronic
6. Safety Probe
7. Temperature probe
8. Vertex socket
9. Resistance
7. Accessories
Please contact Chemglass Life Sciences for more details about accessories.
www.cglifesciences.com Phone: 1-800-843-1794
