1. Connect the detachable power cord to the AC/DC converter (DC power supply) and connect to “INPUT 24Vdc” receptacle in
rear of unit and then plug power cord into a suitable electrical outlet.
2. If purchased, connect an RS232 communications cable to “ Comm.” port in rear of unit and then to a computer.
3. Place one or more spinner vessels atop of unit over magnet marks
SET-UP
(See Figure 1)
24Vdc INPUT Receptacle
Figure 1—Rear Panel
Mains Fuse
1A/250V
Communications Port ( Module
purchased separately ) Optional Motion Alarm
Reset Button
5 Alignment Marks
