MatchBox USB
User Manual
2 – Hardware Installation
Figure 1 - MatchBox USB Connections
Figure 1
As can be seen in
, the unit only has a few notable external features.
1 Power LED
2 USB interface (USB Type A connector)
3 CobraNet Ethernet interface connector and indicators
4 Power socket (9V @ 500mA DC)
© Attero Tech LLC 2009 Page 3 614-00004-05
