MatchBox USB
User Manual
© Attero Tech LLC 2009 Page 10 614-00004-05
5 – Architects & Engineers Specification
The CobraNet interface unit shall provide a USB interface to a PC, over which eight channels of digital audio may be
transmitted or received. Eight channels of CobraNet inputs and eight channels of CobraNet outputs are supplied via the
rear panel RJ-45 connector. The CobraNet interface shall provide the option to select the number of audio channels used as
outputs or inputs from the PC.
The CobraNet interface shall be compatible with Attero Tech Control Center software for flexible control and monitoring in
system applications. The CobraNet interface shall include a UL listed power source. The CobraNet interface shall be
compliant with the RoHS directive.
The CobraNet interface shall be the Attero Tech MatchBox USB.
5.1 – Device Specifications
CobraNet Network
Physical Level: Standard Ethernet
Connector: Single RJ-45
Cable Quality: CAT-5
Transmission Speed: 100 Mbps
Power Requirements 9V DC @ 500mA
Power Consumption 4.5W maximum @ 9V DC
Dimensions 1.6" H x 7.5" W x 6.5" D
Weight 13 oz
Compliance
RoHS, UL Listed power
source, FCC Part 15 Class B
Compliant
USB Connection
Type Standard Type B connector
Speed
Full Speed USB V1.1
(12Megabits/s)
Audio Performance
Standard MatchBox
Stereo Audio Devices
In/Out
0/4, 1/3, 2/2 selectable
MatchBox 1x8
Audio Channels
In/Out
0/8, 2/6, 4/4, 6/2 selectable
