1. FEATURES
• Single Axis Driver for Bipolar step motors
• Operates from +12 to 48 VDC
• Phase currents from 0.3 to 3.0 Amp Peak
NOTE: Phase current of 2.7 Amp and above REQUIRES an additional heatsink,
make sure the temperature of the bracket does not exceed 45° C.
• Hold current reduction capability with adjustable current and timeout settings
• Selectable Step Resolution from Full Step to 256x Microstepping
• Has three optically isolated control inputs and one optically isolated control output
• Pole Damping Technology™ integrated within driver board
Dip switches and a RS485 interface are built-in to the R325P Controller. A USB connection can
be used by using the USB485 Converter Card (sold separately).
2. ELECTRICAL SPECIFICATIONS
Supply Voltage: +12 to 48 VDC
Phase Current: 0.3 to 3.0 Amps Peak
NOTE: Phase current of 2.7 Amp and above REQUIRES an additional heatsink,
make sure the temperature of the bracket does not exceed 45° C.
I/O Specifications
3x Optically Isolated Inputs (1 fixed)
1x Optically Isolated Output
Minimum Motor Impedance: 1.5 mH
Note: The drive may behave unpredictably if the motor you are using has an inductance less
than 1.5 mH.
