background image

8

ELECTRICAL WIRING

WARNING:

ELECTRICAL SHOCK, FIRE OR EXPLOSION
HAZARD

Failure to follow safety warnings exactly could

result in serious injury or property damage.
Improper servicing could result in dangerous

operation, serious injury, death or property

damage.
• Before servicing, disconnect all electrical power

to air handler.

• When servicing controls, label all wires prior

to disconnecting. Reconnect wires correctly.

• Verify proper operation after servicing.

• Electrical connections must be in compliance with

all applicable local codes and ordinances, and with

the current revision of the National Electric Code

(ANSI/NFPA 70).

• For Canadian installations, the electrical connections

and grounding shall comply with the current Canadian

Electrical Code (CSA C22.1 and/or local codes).

Line Voltage

An electrical disconnect must be located within sight

of and readily accessible to the unit. This switch shall

be capable of electrically de-energizing the outdoor unit.

See unit data label for proper incoming field wiring. Any

other wiring methods must be acceptable to authority

having jurisdiction.

• It is recommended that the line voltage to the unit be

supplied from a dedicated branch circuit containing the

correct fuse or circuit breaker for the unit.

• Overcurrent protection must be provided at the branch

circuit distribution panel and sized as shown on the unit

rating label and according to applicable local codes. See

the unit rating plate and Table 2 for maximum circuit

ampacity and maximum overcurrent protection limits.

• Refer to the unit wiring label for proper high and low

voltage wiring.

• Use only copper wire for the line voltage power supply

to this unit. Use proper code agency listed conduit and

a conduit connector for connecting the supply wires to

the unit.

• If replacing any of the original wires supplied with the

unit, the replacement wire must be copper wire consisting

of the same gauge and temperature rating.

• Provide power supply for the unit in accordance with

the unit wiring diagram, and the unit rating plate. The

installer should become familiar with the wiring diagram/

schematic before making any electrical connections to
the unit. See Figures 5 & 6 (pages 14 & 15).

• All 208/230 Volt units are shipped from the factory wired

for 240 volt operation. For 208V operation, remove the

lead from the transformer terminal marked 240V and

connect it to the terminal marked 208V.

Grounding

WARNING:

The unit cabinet must have an uninterrupted
or unbroken electrical ground to minimize
personal injury if an electrical fault should occur.
Do not use gas piping as an electrical ground!

This unit must be electrically grounded in accordance

with local codes or, in the absence of local codes, with

the National Electrical Code (ANSI/NFPA 70) or the CSA

C22.1 Electrical Code. Use the grounding lug provided in

the control box for grounding the unit.

Minimum Circuit Ampacity & Maximum Overcurrent Protection

Model #

FMG-

240VAC, 50 & 60Hz

208VAC, 50 & 60Hz

MCA

MOP

MCA

MOP

FMG1805X1E

29.8

30

26.2

30

FMG1808X1E

43.3

45

38.8

40

FMG2405X1E

29.8

30

26.2

30

FMG2408X1E

43.3

45

38.8

40

FMG2410X1E

54.8

60

47.8

50

FMG2505X1E

29.8

30

26.2

30

FMG2508X1E

44.3

45

38.8

40

FMG2510X1E

54.8

60

47.8

50

FMG3005X1E

29.8

30

26.2

30

FMG3008X1E

44.3

45

38.8

40

FMG3010X1E

54.8

60

47.8

50

FMG3605X1E

29.8

30

26.2

30

FMG3608X1E

44.3

45

38.8

40

FMG3610X1E

54.8

60

47.8

50

MCA = Minimum Circuit Ampacity, MOP = Maximum Over-Current
Protection

Table 2. Electrical Rating Data

Thermostat Connections

• Thermostat connections shall be in accordance with the

instructions supplied with the thermostat and the indoor

equipment. The low voltage wires must be properly

connected to the units low voltage terminal block.

• A single stage thermostat is used with this equipment

and must operate in conjunction with any installed

accessories. Typical AC and air handler hookups are

shown in Figure 3 (page 9).

• The thermostat should be mounted about 5 feet above

the floor on an inside wall. DO NOT install the thermostat

on an outside wall or any other location where its

operation may be adversely affected by radiant heat from

fireplaces, sunlight, or lighting fixtures, and convective

heat from warm air registers or electrical appliances.

Refer to the thermostat manufacturer’s instruction sheet

for detailed mounting and installation information.
