Rivera Primo Mid-Controls User Manual
Page 9
Shifter Support Tube Assembly
Qty Part Number
Description
1
2084-0050
Shifter Support Tube Photo 13
2
2084-0048
Bronze Bushings Photo 13
Shifter Lever Assembly
Qty Part Number
Description
Photo 14
1
2084-0055
Shifter Lever Mounting Block
Photo 15A
1
2084-0053
Shifter Lever
Photo 15B
1
2084-0073
Shifter Lever Retainer
7
2100-0048
10-24 x 1.125” SHCS
Shifter Linkage Assembly
Qty Part Number
Description
Photo 25
1
Welded Shifter Linkage
Photo 20
3
2101-0008
.125” x .750” Dowell Pins
Photo 21
1
1101-0018
Curved Disc Spring Washer
Photo 22
1
1101-0020
Thrust Washer (Small)
Photo 23
1
1101-0022
Thrust Washer (Large)
Photo 24
1
2100-0047
5/16-18 x 1.00” SHCS
Shifter Rod End Assembly
Qty
Part Number
Description
Photo 26
2
2018-0099
Rod Ends 5-16-24 Female
1
2084-0080
Rod 5/16-24 Male Each End
2
1100-0017
5/16-24 x 1.00” SHCS
1
2100-0044
5/16-24 Center Locknut
* NOTE: USE BLUE LOCTITE ON ALL FASTENERS
S
SHIFT SIDE ASSEMBLY. . . P/N 2084-0500
ITEMIZATION OF PARTS
Photo 13
Photo 14
Photo 15A
Photo 15B
2084-0050
2084-0048
Top Front
2084-0073
2100-0048
2084-0053
Line-up Hole
2084-0055
Line-up Hole
