APG Cash Drawer Model 484A SerialPRO II - Manual (Page 4)

CHART #1 - PULSE EDGES PER ASCII CHARACTER
NON-PRINTABLE ASCII CHARACTERS PRINTABLE ASCII CHARACTERS
Number Number Number Number
ASCII Control Dec. Hex of Pulse ASCII Dec. Hex of Pulse ASCII Dec. Hex of Pulse ASCII Dec. Hex of Pulse
Character Character Num Num Edges Character Num Num Edges Character Num Num Edges Character Num Num Edges
NUL <@> 0 0 1 space 32 20 2 @ 64 40 2 ` 96 60 2
SOH 1 1 2 ! 33 21 3 A 65 41 3 a 97 61 3
STX 2 2 2 " 34 22 3 B 66 42 3 b 98 62 3
ETX 3 3 2 # 35 23 3 C 67 43 3 c 99 63 3
EOT 4 4 2 $ 36 24 3 D 68 44 3 d 100 64 3
ENQ 5 5 3 % 37 25 4 E 69 45 4 e 101 65 4
ACK 6 6 2 & 38 26 3 F 70 46 3 f 102 66 3
BEL 7 7 2 ' 39 27 3 G 71 47 3 g 103 67 3
BS 8 8 2 ( 40 28 3 H 72 48 3 h 104 68 3
HT 9 9 3 ) 41 29 4 I 73 49 4 i 105 69 4
LF 10 A 3 * 42 2A 4 J 74 4A 4 j 106 6A 4
VT 11 B 3 + 43 2B 4 K 75 4B 4 k 107 6B 4
FF 12 C 2 , 44 2C 3 L 76 4C 3 l 108 6C 3
CR 13 D 3 - 45 2D 4 M 77 4D 4 m 109 6D 4
SO 14 E 2 . 46 2E 3 N 78 4E 3 n 110 6E 3
SI <0> 15 F 2 / 47 2F 3 O 79 4F 3 o 111 6F 3
DLE
16
10 2 0 48 30 2 P 80 50 3 p 112 70 2
DC1 17 11 3 1 49 31 3 Q 81 51 4 q 113 71 3
DC2 18 12 3 2 50 32 3 R 82 52 4 r 114 72 3
DC3 19 13 3 3 51 33 3 S 83 53 4 s 115 73 3
DC4 20 14 3 4 52 34 3 T 84 54 4 t 116 74 3
NAK 21 15 4 5 53 35 4 U 85 55 5 u 117 75 4
SYN 22 16 3 6 54 36 3 V 86 56 4 v 118 76 3
ETB 23 17 3 7 55 37 3 W 87 57 4 w 119 77 3
CAN 24 18 2 8 56 38 2 X 88 58 3 x 120 78 2
EM 25 19 3 9 57 39 3 Y 89 59 4 y 121 79 3
SUB 26 1A 3 : 58 3A 3 Z 90 5A 4 z 122 7A 3
ESC <[> 27 1B 3 ; 59 3B 3 [ 91 5B 4 { 123 7B 3
FS 28 1C 2 < 60 3C 2 \ 92 5C 3 | 124 7C 2
GS <]> 29 1D 3 = 61 3D 3 ] 93 5D 4 } 125 7D 3
RS <^> 30 1E 2 > 62 3E 2 ^ 94 5E 3 ~ 126 7E 2
US <-> 31 1F 2 ? 63 3F 2 _ 95 5F 3 DEL 127 7F 2
NOTE: If serial port is set for 7 bit characters, subtract 1 pulse from ASCII characters "@" (hex 40) to "DEL" (hex 7F).
M-23G-484A Rev - Copyright 2002 APG ® Cash Drawer
