User Manual

DI170S01-A01

DI170S01-A01
Product No. : SA-02-015

Rev 1

May 23, 2005

Page 6 of 16

5.4 Connector Pin Assignment

5.4.1 CN6: DC Input

Part No.

Pin No.

Description

Remarks

PHR-4
(JST)

1,2
3,4

GND
Vcc(12V/5A)


5.4.2 CN1: Analog RGB Input

Part No.

Pin No.

Description

Remarks

S13B-PH-SM3-TB
(JST)

1
2
3
4
5
6
7
8
9
10
11
12
13

CABLE DETECT
DDC SDA
DDC SCL
RED GND
RED INPUT
GREEN GND
GREEN INPUT
BLUE GND
BLUE INPUT
NC
VERTICAL SYNC
SYNC GND
HORIZONTAL SYNC


5.4.3 CN2: Key Connector

Part No.

Pin No.

Description

Remarks

53261-1490
(MOLEX)

1
2
3
4
5
6
7
8
9
10
11
12
13
14

LED2
LED1
GND
POWER
GND
MENU
RIGHT (Brightness +)
NC
NC
LEFT (Brightness -)
EXIT
AUTO
GND
+3.3V (100mA)








Option in 8 keys
Option in 8 keys
