User Manual
DI170S01-A01
DI170S01-A01
Product No. : SA-02-015 Rev 1
May 23, 2005
Page 3 of 16
1 Revision History
Date Rev.No. Description Page
10.02.2005 0 First release of datasheet
23.05.2005 1 Final release
2 General Description
The DI170S01-A01 from Distec’s CompactPanel Series is an open frame monitor providing an analog RGB interface for
17” SXGA TFT LCD panels with a high quality screen image. This monitor supports from VGA to UXGA resolution at a
maximum of 85Hz refresh rate (refer to point 8.1) with automatic up- and downscaling function to full screen size.
It gives a lot of convenience to the user in installing various applications such as gaming, amusement, industry and so
on and accessing the GUI (Graphic User Interface).
The DI170S01-A01 is a certified product.
3 Absolute Maximum Ratings
ITEM DESCRIPTION REMARKS
Model Name DI170S01-A01
LCD Module LTM170EU-L21 Refer to the clause 5.1 Panel
Specification
Input Signal Analog RGB
DC 12V/2.6A *
* Measured at 23°C ambient temperature
Resolution Horizontal: Typ. 64, Max. 82.1 KHz
Vertical: Typ. 60, Max. 77 Hz
Analog RGB : VGA/SVGA/XGA/SXGA/UXGA Special timing available
1600x1200 @ 60Hz Max.
Receptacle DC Jack, KEY Connector, RGB Connector
User Controls 5 Buttons Controls
Image Scaler gm2121 Genesis Microchip
Power Consumption 31W Max * * Measured at 23°C ambient temperature
Dimension Refer to the clause 6.1
Plug & Play DDC 2B VESA
Power Management Supports VESA DPMS
