8 Appendix
8.1 Standard Timing Chart
Total Horizontal H- Vertical V- Pixel Failsafe
Pixels Frequency Pol. Freq Pol. Clock Mode
Mode Active Resolution
(KHz) (Hz)
VGA 640x350 @ 85Hz 832x445 37,861 P 85,08 N 31,5 X
640x400 @ 85Hz 832x445 37,861 N 85,08 P 31,5 X
720x400 @ 85Hz 936x446 37,927 N 85,039 P 35,5 X
640x480 @ 60Hz 800x525 31,469 N 59,94 N 25,175
640x480 @ 72Hz 832x520 37,861 N 72,809 N 31,5
640x480 @ 75Hz 840x500 37,5 N 75 N 31,5
640x480 @ 85Hz 832x509 43,269 N 85,008 N 36 X
SVGA 800x600 @ 56Hz 1024x625 35,156 N/P 56,25 N/P 36
800x600 @ 60Hz 1056x628 37,879 P 60,317 P 40
800x600 @ 72Hz 1040x666 48,077 P 72,188 P 50
800x600 @ 75Hz 1056x625 46,875 P 75 P 49,5
800x600 @ 85Hz 1048x631 53,674 P 85,061 P 56,25 X
XGA 1024x768 @ 60Hz 1344x806 48,363 N 60,004 N 65
1024x768 @ 70Hz 1328x806 56,476 N 70,069 N 75
1024x768 @ 75Hz 1312x800 60,023 P 75,029 P 78,75
1024x768 @ 85Hz 1376x808 68,677 P 84,997 P 94,5 X
1152x864 @ 75Hz 1600x900 67,5 P 75 P 108
SXGA 1280x1024 @ 60Hz 1688x1066 63,981 P 60,02 P 108
1280x1024 @ 75Hz 1688x1066 79,976 P 75,025 P 135
EGA 640x350 @ 70Hz 800x449 31,469 P 70,086 N 25,175
CGA 640x400 @ 70Hz 800x449 31,469 N 70,086 P 25,175
DOS 720x350 @ 70Hz 900x449 31,469 P 70,087 N 28,322
DOS 720x400 @ 70Hz 900x449 31,469 N 70,087 P 28,322
XGA 1024x768 @ 72Hz 1304x798 57,515 P 72,1 P 75
XGA 1024x768 @ 87Hz(i) 1264x817 35,522 P 43,479 P 44,9
640x480 @ 67Hz 864x525 35 N 66,667 N 30,24
SVGA 832x624 @ 75Hz 1152x667 49,725 N 74,551 N 57,283 X
XGA 1024x768 @ 60Hz 1312x813 48,78 N 60,001 N 64
SXGA 1280x1024 @ 60Hz 1708x1056 63,337 N 59,978 N 125
1280x1024 @ 72Hz 1728x1085 78,125 N 72,005 N 135
SXGA 1280x1024 @ 67Hz 1696x1056 70,755 N 67,003 N 120
1280x960 @ 60Hz 1800x1000 60 P 60 P 108
1280x1024 @ 85Hz 1728x1072 91,146 P 85,024 P 157,5 X
1280x960 @ 85Hz 1728x1011 85,934 P 85,002 P 148,5 X
VGA 640x400 @ 56Hz
1152x864 @ 70Hz 1600x900 P 70 P
UXGA 1600x1200 @ 60Hz X
1280x768 @ 60Hz
1280x720 @ 60Hz
