Rugged Ridge Mesh Summer Brief, 10-14 Jeep Wrangler (JK) - Manual (Page 2)

Part Number: 13579.XX, 13588.XX
Jeep® JK Wrangler Summer Top ( 2DR)
Page 2 of 3
(Step 4) - Pull rear straps over side roll bar and secure plastic hook to body tub as shown. Pull snug
but do not tighten at this time.
(Step 7) (Step 8) (Step 9)
(Step 4) (Step 5) (Step 6)
(Step 5) - Loop Velcro side straps around and under door surrounds.
(Step 6) - Pull straps up between surrounds and side of roll bar. Pull strap around roll bar and secure
back to strap as shown. Front (header strap) should be pulled under front plastic trim.
(Step 7) - Center straps (with buckle) are secured around center post (B-pillar). Pull straps around post
just above plastic trim. Pull strap tight.
(Step 8) - Secure roll bar flaps as shown. Flaps have been designed to work with roll bar grab handles.
Grab handles should be positioned between flap cutouts.
(Step 9) - With all side Velcro straps secured go back and tighten sound bar straps, and rear hook
straps. Pull tight until top is smooth.
