Rugged Ridge Sailcloth Bowless XHD Soft Top, Spice, 97-06 Jeep Wrangler User Manual
Page 5
Page 5 of 7
(Step 25) - Slide rear window tailgate bar onto top (pic.24). Please note that rear tailgate bar is not
supplied with the bowless top. The rear bar is to be reused from factory hardware. If rear
bar is needed please order Rugged Ridge part number (13550.01).
(pic.23)
(pic.24)
(pic.25)
(step 24) - Check side Velcro flaps to insure they are tight around door surround (pic.23).
(Step 27) - Pull rear window down and lock rear tailgate bar into body tub retainer bracket (pic.26).
.
(Step 29) - Pull rear window zippers down and seal with Velcro flaps (pic.28).
(Step 28) - Pull and lock plastic retainer flaps into body tub (pic.27).
(pic.26)
(pic.27)
(pic.28)
Jeep® TJ Wrangler XHD Bowless Top (With Door Hardware)
Part Number: 13751.01
13751.35
13751.37
(step 26) - Pull rear window zippers down (pic.25). Check rear tub straps to insure they are still tight.
Rev.1 3/14/2012
