Rugged Ridge Bowless XHD Soft Top, Spice, 97-06 Jeep Wrangler (TJ) User Manual
Page 4
Jeep® TJ Wrangler XHD Bowless Top (With Factory Door Surrounds)
Page 4 of 6
(Step 17) - Pull side window to bowless top zipper all the way back. Pull sides of bowless top
over side window and secure Velcro. Repeat for other side.
(Step 18) - Slide rear window tailgate bar onto top. Please note that rear tailgate bar is not supplied
with the bowless top. The rear bar is to be reused from factory hardware. If rear bar is
needed please order Rugged Ridge part number (13550.01).
(Step 16)
(Step 17)
(Step 18)
Part Number: 13750.35
13750.36
(Step 16) - Working from the front of the vehicle pull side window lower plastic retainer down and
lock into body. Pull rear corner down and lock into body. Repeat for other side.
(Step 19) - Pull rear window down and lock rear tailgate bar into body tub retainer bracket.
.
(Step 21) - Pull rear window zippers down and seal with Velcro flaps.
(Step 20) - Pull and lock plastic retainer flaps into body tub.
(Step 19)
(Step 20)
(Step 21)
