Installation instructions ( p/n: 13235.XX)
2007-2013 Jeep® Wrangler JK - Neoprene Front Seat Vest.
2-door and 4-door (front seats only)
Parts included: (1) Front driver's side seat vest
(1) Front passenger's side seat vest
Instructions:
Step(1)
Step (2)
Step (1) Slide, and tilt back of seat forward
Step (2) Remove Head rest
Step (3) Slip vest over back of seat
Step (4) Slip lower nylon strap and
clip between the upper and
lower portions of the seat.
Step (5) Slip Velcro straps through
lower straps plastic loops as
shown.
Step (3)
Step (4)
Step (6) position the side straps in
front of seat adjuster as shown.
Driver's side adjust seat up
as high as possible using the
seat height adjuster lever.
Slip straps between raised seat
and seat riser. Clip straps
together and adjust.
DO NOT OVER TIGHTEN.
Step (5)
Step (6)
Passenger's side place the rear
strap underneath the seat slider and
and seat riser. Adjusting the seat
forward or backwards may help
with locating and pulling inner
most tabs near console. The front
straps should be run under the front
of the seat just behind the seat slider
adjustment arm. Adjust straps but
DO NOT OVER TIGHTEN!
®
